Reference Compact Surround Sound Home Theater 5.1 Channel Speaker System with DB12 Subwoofer
Black Ash (X851BC)
Reference Compact Surround Sound Home Theater 5.1 Channel Speaker System with DB12 Subwoofer
HIGH PERFORMANCE 5.1 SPEAKER SYSTEM
Engineered with premium components to pack a powerful punch of room-filling music delivering a truly immersive home audio experience featuring front bookshelf speakers, a center channel, rear surround speakers and DB12 Subwoofer
EXQUISITE BOOKSHELF SURROUNDS
As impactful as tower speakers, with outstanding clarity and immersive sound reproduction, these bookshelf speakers are perfect as fronts or surround speakers
POWERFUL 12" SUBWOOFER
Low distortion amplifier provides continuous 240 watts of clean, dynamic power (400w peak) to deliver heart pounding bass at the most intense music and movie climaxes
SUPERIOR CABINET ENGINEERING
Meticulously designed wood enclosure to avoid unwanted resonance with front firing bass ports for improved bass response
COMPACT HOME THEATER SYSTEM
Full range sound from the powerful midrange drivers and the premium Neodymium tweeters, delivering captivating surround sound throughout your entire room
Overview
Specifications
Reference High Performance 2-Way Center Channel Speaker
| Speaker Configuration | 2 Way - 3 Driver Center Channel |
|---|---|
| Tweeter | 1 inch Neodymium Balanced Silk Dome Ferrofluid Cooled |
| Woofer | Dual 5.25 inch Woven Glass Fiber Composite Drivers with Butyl Rubber Surrounds |
| Power Handling | 50 - 100 Watts RMS |
| Frequency Response | 110Hz - 20KHz |
| Sensitivity | 86dB @ 1W / 1m |
| Crossover Frequency | 3000 Hz Phase Coherent - PCB Mounted Circuitry |
| Impedance | 8 Ohm Compatible |
| Enclosure | Acoustic Suspension Design |
| Dimensions | 6.9 X 18.5 X 9.0 inches (HxWxD) |
| Speaker Weight | 15 pounds |
| Series | REFERENCE |
| Certifications | CE Certified |
| Subwoofer Output | 0 |
| DOLBY ATMOS | Ideal for use as surround sound speakers in a Dolby Atmos Surround Sound |
| Frequency Response Graph | Click to Expand |
| UPC | 61783269718 |
| What's Included |
|
Reference High Performance 2-Way Bookshelf and Surround Speakers
| Speaker Configuration | 2 Way - 2 Driver Surround Speakers (Wall Mountable) |
|---|---|
| Tweeter | 1 inch Neodymium Balanced Silk Dome Ferrofluid Cooled |
| Woofer | 5.25 Inch Woven Glass Fiber Composite Drivers with Butyl Rubber Surrounds |
| Power Handling | 40 - 80 Watts RMS |
| Frequency Response | 50Hz - 20KHz |
| Sensitivity | 85dB @ 1W / 1m |
| Crossover Frequency | 3100 Hz Phase Coherent - PCB Mounted Circuitry |
| Impedance | 8 Ohm Compatible |
| Enclosure | Vented Bass-reflex Design |
| Dimensions | 11.4 x 8.1 x 9.0 inches (HxWxD) |
| Speaker Weight | 11.35 pounds/speaker |
| Series | REFERENCE |
| Certifications | CE Certified |
| Subwoofer Output | 0 |
| DOLBY ATMOS | Ideal for use as surround sound speakers in a Dolby Atmos Surround Sound |
| Frequency Response Graph | Click to Expand |
| UPC | 61783269732 |
| What's Included |
|
DB12 12-inch Low Frequency Ported Front Firing Powered Subwoofer
| Speaker Configuration | Front Firing Powered Subwoofer with Integrated Amplifier |
|---|---|
| Low-Frequency Driver | 12-inch Long Throw Polypropylene with Rubber Surround |
| Amplifier Power | Peak 400W / RMS 240W |
| Input | Line/Low Level Subwoofer (RCA L/R) and Speaker/High Level |
| Audio Output | Line/Low Level Subwoofer (RCA L/R) and Speaker/High Level |
| Low-Pass Crossover | 40Hz – 180Hz |
| Frequency Response | 36Hz – 180Hz (%C2%B13dB) Full Range Anechoic Measurement 34Hz – 180Hz (%C2%B16dB) Full Range Anechoic Measurement |
| Power | 120VAC (60Hz) |
| Cabinet Specifications | Precision Crafted MDF Internally Braced |
| Enclosure | Front Firing Tuned Bass Reflex Vented Via Port |
| Phase Adjustment | Reverse & Normal |
| AUTO FUNCTION | Yes – (100Hz signal input reach 3mV, 1KHz input 5mV) |
| Gain Control | 1 |
| Dimensions | 16.7 x 15 x 16.8 inches / 42.4 x 38.1 x 42.7 cm (HxWxD) |
| Speaker Weight | 37 lbs |
| Certifications | ICES FCC Certified ETL/CETL |
| Fluance Speaker Size Comparison Chart | |
| UPC | 061783265567 |
| What's Included |
